API X60 5L PSL 2 Pipes

 SPECIFICATIONS

Trade Name : API 5L X60 PSL 2 Pipes
Sizes (Seamless) : 1/2” NB – 60” NB
Sizes (ERW): 1/2” NB – 24” NB
Sizes (SAW) : 16” NB – 100” NB
Sizes LSAW/DSAW : 16’OD TO 54′ OD (8 MM TO 50 MM THK)
Wall Thickness : 5.5mm-25.5mm,
surface : Bare, varnished, black lacquer, , 3PE,FBE,Epoxy, as per customer’s requirement;
Packing : Usually in loose pieces; can be packed as customers’ special requirements

Categories: ,
Contact Us
Request a Quote

PT. Cahaya Bina Baja is a distributor of API 5L X60 PSL 2 Pipes that are being completely tested on diverse parameters so as to ensure its flawlessness. Our company is regarded as a specialist in offering a huge array of these API 5L X60 PSL 2 Seamless Pipes, which is been fabricated by making use of latest machinery and equipment. These API 5L X60 PSL 2 Welded Pipes are ideal to be used in the field of bending, welding, flanging and similar tasks in the industrial fronts. Our API 5L X60 PSL 2 EFW Pipes is known for its Elegantly Designed, Fine - finish, High efficiency, Super strength, and so on. To increase the size, these API 5L X60 PSL 2 ERW Pipes are used at the outlet side of the expansion joint. Our API 5L X60 PSL 2 Round Pipes is suitable for water, conveying gas, and oil.

LIST OF API 5L X60 PSL 2 PIPE

API 5L GRADE X60 PSL 2 PIPES CHEMICAL COMPOSITION

CHEMICAL COMPOSITION

Mass fraction, based upon heat and product analysis % maximum carbon equivalent a
% maximum
CB SI MNB P S V NB TI other CEIIW CEPcm
Seamless & welded pipes
L320N or x60N 0. 24F 0. 45F 1.4F 0.025 0.015 0.10F 0. 05 0. 04 G,H 0.43 0.25
L320Q or x60Q 0.18F 0.45F 1.5F 0.025 0.015 G G G H 0.43 0.25
Welded pipe
L290m or x60M 0.22F 0.45F 1.4F 0.025 0.015 G G G H 0.43

API 5L GR X60 PSL 2 PIPES MECHANICAL PROPERTIES:

MECHANICAL REQUIREMENTS

Y.S T.S ELONGATION
MPA(psi) MPA(psi)
min min min
415(60 200) 520(75 400 F

DIFFERENT TYPES OF API 5L X60 PSL 2 PIPES

  •  API 5L X60 PSL 2 Carbon Steel Seamless Pipes
  •  API 5L X60 PSL 2 Schedule 40 Black Pipe
  •  API 5L X60 PSL 2 Carbon Steel SAW Pipes
  •  API 5L X60 CS PSL 2 Pipe
  •  API 5L Gr X60 PSL 2 LSAW Pipes
  •  API 5L X60 PSL 2 Seamless Pipe
  •  API 5L X60 PSL 2 Sch.40 Black Steel Line Pipe
  •  API 5L X60 PSL 2 Carbon Steel Pipes
  •  API 5L X60 PSL 2 Nace + Hic Line Pipes
  •  API 5L Gr X60 PSL 2 ERW Pipes
  •  Carbon Steel API 5L X60 PSL 2 Nace + Hic Pipe
  •  API 5L X60 PSL 2 Welded Pipe Weight
  •  API 5L Gr.X60 PSL 2 SMLS Line Pipes
  •  API 5L X60 PSL 2 Carbon Steel HIC Tested Line Pipe
  •  API 5L Grade X60 PSL 2 Seamless Pipe
  •  API 5L X60 PSL 2 Round Pipes
  •  API 5L X60 PSL 2 Schedule 80 SMLS Pipe
  •  API 5L X60 PSL 2 Schedule 80 DSAW Pipe

APPLICATION AND MATERIAL OF API 5L X60 PSL 2 PIPE

  •  API 5L X60 PSL 2 Pipe used for Refineries
  •  API 5L X60 PSL 2 Line Pipe used for Power Plants
  •  API 5L X60 PSL 2 Pipe used for Marine Applications
  •  API 5L X60 PSL 2 Line Pipe used for Off-Shore Oil Drilling Companies
  •  API 5L X60 PSL 2 Pipe used for Fossil Fuel Power Plants
  •  API 5L X60 PSL 2 Pipe used for Ship Building
  •  API 5L X60 PSL 2 Line Pipe used for Nuclear Power
  •  API 5L X60 PSL 2 Pipe used for Paper & Pulp
  •  API 5L X60 PSL 2 Line Pipe used for Gas Processing
  •  API 5L X60 PSL 2 Pipe used for Sea Water Equipment
